1. Radar wave open channel flowmeter

2. What are the measurement ranges of electromagnetic flowmeters?

1、 Electromagnetic flowmeter is a very sensitive flowmeter that can measure the flow rate of conductive liquids. It is also economical and has a diameter of generally DN10-- DN2000. It can measure sewage or corrosive liquids and has a wide range of applications;

2、 Electromagnetic flow meters can only measure volumetric flow rates, with units such as m3/h (cubic meters/hour), L/min (liters/minute), etc. They have pure grinding instantaneous flow rate display and cumulative flow rate display;

3、 The measurement range corresponding to electromagnetic flow meters of different diameters is: (unit: m3/h): DN10:0.03-4.24; DN15：0.06---9.54； DN20：0.12---16.96； DN25：0.18---26.5； DN32：0.29---43.42； DN40：0.45---67.85； DN50：0.7---106； DN65

1.19---179； DN80

1.8---271； DN100：2.28---424； DN125：4.41---662.。。。。。 For more detailed information, please refer to the technical article on the website of Shandong Qiangsheng Automation Technology Co., Ltd.... Www.qszdh.com

3. Measurement range of electromagnetic flowmeter

Electromagnetic flowmeter has a large measurement range, usually from 20:1 to 50:1, with a wide range of optional flow rates; The aperture range of electromagnetic flow meters is wider than other types of flow meters, ranging from a few millimeters to 3 meters; It can measure both positive and negative flow rates, as well as pulsating flow rates, as long as the manual frequency of the dust hail pulse is much lower than the excitation frequency; The instrument output is essentially linear; Easy to choose the material variety for the contact pa

rts with the fluid, and can be applied to corrosive fluids and other advantages. Due to the fact that electromagnetic flow meters have a much higher chance of measuring suspended solids or pollutants compared to other flow meters, the probability of failure caused by the adhesion layer on the inner wall is relatively high. If the conductivity of the adhesion layer is similar to that of the liquid, the instrument can still output signals normally, but only change the flow area, resulting in an implicit fault of measurement error; If there is a high conductivity adhesion layer, the electromotive force between the electrodes will be short circuited; If it is an insulating adhesive layer, the electrode surface will be insulated and the measurement circuit will be disconnected. Both of the latter two phenomena will cause the instrument to malfunction.

4. What are the measurement ranges of electromagnetic flow meters? The range of an electromagnetic flowmeter depends on multiple factors, including its size and diameter, design parameters, and the physical properties of the fluid being measured. Under normal circumstances, electromagnetic flow meters can provide a fairly wide measurement range. Here are some reference data: the flow velocity measurement range is generally 0.05 to 10 meters per second (m/s). According to the different nominal diameters (DN) of Zhengzhuo, the measurable flow range varies: for example, for a DN10 electromagnetic flowmeter, the measurable flow range is approximately between 0.0142 and 3.3912 cubic meters per hour (m ³/h). The effective measurement flow range of DN15 electromagnetic flowmeter may be 0.0318 to 7.6302 m ³/h. The measurement range of electromagnetic flow meters is usually large
