1. How to determine the K value of a GF flowmeter based on the pipe material and diameter, such as PVC80 and PVC100 pipes?

On the official website of Georg Fischer (GF) or Combustion, there is a "Support and Service" - "Online Tool" section on the shirt core surface, which contains many free software, including: K coefficient calculator. You can go to "Georg Fischer Duan Linger" on Baidu and take a look yourself, hoping it will be useful to you.

2. What is the malfunction of the nosensor displayed on the GF electromagnetic flowmeter?
? When the electromagnetic flowmeter displays a "no sensor" fault, the first thing to check is whether the sensors connection wire is normal. If the coil resistance of the sensor is below 730 ohms, it is likely that the sensor is damaged. If the coil resistance is normal, it is necessary to check whether the signal line is in good contact and whether there is any disconnection or short circuit. If there is no problem with the signal line, the next step is to check whether the sensor itself is damaged or needs calibration. If the sensor is installed improperly or there is foreign object interference, it may also cause the signal display to crack. After troubleshooting these hardware issues, if the problem still cannot be resolved, it may be necessary to consider checking whether the communication protocol or software settings between the sensor and the flow meter are correct.

3. How to calibrate GF8550-1 rotor flowmeter ɘ

After installing the flowmeter, let the pipeline fluid be transported normally. It is best to circulate only when the fluid is not in use, so that t

he actual flow rate is as stable as possible. The panel will display a flow rate value, but it is uncertain whether it is consistent with the actual flow rate. The following is the calibration. Find another calibrated flow meter (usually using a calibrated handheld ultrasonic flow meter, how to use it will not be explained), measure the actual flow rate in the pipeline, compare it with the GF panel, and if the display is inconsistent, adjust your GF flow meter by following these steps (up key for up, down key for down): Press and hold the "ENTER" key for 2 seconds to enter the calibration interface (dont press it too long, 5 seconds will enter the operation interface, if you need a password, the default is "up, up, down"). Press up or down to find "FLOW K-FACTOR", adjust the value of this item, and then hold down both the up and down buttons to save and exit (of course, you dont know how many FLOW K-FACTOR settings you need to set, so you need to enter several times and adjust according to the value you set and the changes in flow rate). When the flow value is adjusted to match the value of the other flowmeter, record the FLOW K-FACTOR value. Go back to the calibration interface and find TOTALL K-FACTOR. Set the value to match the FLOW K-FACTOR, save and exit. FLOW K-FACTOR is a parameter for real-time traffic, while TOTALL K-FACTOR is a parameter for cumulative traffic. You can also download the K value calculator from its website, fill in your pipeline information and probe type, calculate the K value you want, and make changes directly. This way, no other flow devices are needed, but it is unclear whether there is an error.
