1. The meaning of the Yokogawa AXG electromagnetic flowmeter model
The "AXG" in the Yokogawa AXG electromagnetic flowmeter model represents the ADMAG TI series to which it belongs, and the following number is directly checked to indicate the instrument diameter size in millimeters. 1. Analysis of Model Meaning: The specific model of Yokogawa AXG electromagnetic flowmeter (such as AXG00
2, AXG005) follows a clear naming convention: • "AXG": This is the product series code, representing its belonging to Yokogawas ADMAG TI (Total Insight) series. The numerical part (such as 002, 005): This string of numbers directly represents the diameter (caliber) of the flowmeter, measured in millimeters (mm). For example: - AXG002 represents a caliber of 2 mm - AXG005 represents a caliber of 5 mm - AXG010 represents a caliber of 10 mm. 2. The correspondence between model and caliber is a very intuitive naming method for wheels, and users can directly determine the basic size specifications of the equipment through the model number. The corresponding relationship between common models and calibers is as follows: | Model | Caliber (mm) | |: --- |: --- | | AXG002 | 2 | | AXG005 | 5 | | AXG010 | 10 | | AXG015 | 15 | | AXG025 | 25 | | AXG040 | 40 | | AXG050 | 50 | | AXG080 | 80 | AXG100 | 100 | | AXG150 | 150 | | AXG200 | 200 | | AXG250 | 250 | AXG300 | 300 | 3. When selecting a model, it is not only necessary to rely on the pure excavation diameter, but also to confirm other key parameters to ensure compatibility with your working conditions: • Measurement medium: must be a conductive liquid. Lining material: It needs to be selected according to the corrosiveness and temperature of the medium (such as PTFE, hard rubber, etc
2. How to handle the Err20 report of the Henghe electromagnetic flowmeter se14m
The processing method for the Err20 report of the Henghe electromagnetic flowmeter se14m is as follows:
1. Check the power supply and cable connection: Ensure that the power supply of the electromagnetic flowmeter is normal, and the cable connection is stable and can be buried.
.2、 Check sensor installation: Confirm that the sensor is correctly installed on the pipeline and that Wang Shen has no physical damage or blockage.
3、 Check liquid conditions: Ensure that the liquid medium meets the requirements of the electromagnetic flowmeter, including temperature, pressure, conductivity, etc.
4、 Recalibrate or Reconfigure: If possible, try recalibrating or reconfiguring the electromagnetic flowmeter. This can be done by referring to the operating manual of the device.
3. Fault codes and solutions for Yokogawa electromagnetic flowmeter
The fault codes for Yokogawa Dianzhou Xiaoci flowmeter are divided into two categories: "with code alarm" and "no code abnormality", corresponding to different maintenance directions.
.1. Handling of simulated wheel tracks with code 1 Code E004 (communication failure) • Possible causes: abnormal physical connection of communication lines, mismatched protocol parameters between devices, and hardware damage to communica
