Foxboro Mag Flow Meter Troubleshooting: Diagnosing IMT Transmitters and 9100A Sensor Signal Faults
Quick Answer: For most Foxboro mag flow meter faults, start at the transmitter. Check the IMT excitation current, wiring and empty pipe detection. Then move to the 9100A sensor. Test coil resistance, electrode leakage and ground continuity. If the sensor values are outside the factory test sheet range, replace the sensor or plan a re-line.
Why Foxboro IMT Transmitters Report Signal Faults
Many callouts start with a signal error on an IMT25, IMT30, IMT31 or IMT33 display. In practice we see three causes most often. The first is moisture inside the terminal box on a 9100A sensor. The second is a failed signal cable shield connection. The third is an empty pipe condition that the transmitter reads as a signal fault.
Before opening the transmitter, record the error code and the flow reading. Check if the pipe is full. A partially full pipe on a DN200 wastewater line gives unstable electrode signals. If the pipe is full, open the IMT terminal cover only after the area is safe. Use a multimeter to measure the excitation voltage between coil terminals. A missing or very low excitation voltage usually points to the IMT power board or a broken cable pair.
You can also check the electrode signal at the transmitter terminals. Use a portable process meter with 0.1 mV resolution. Set the meter to AC or DC mV depending on your IMT version. In a stable flow you should see a small signal, often 2 to 15 mV on a medium conductivity process like potable water. A dead signal with full pipe and 20 µS/cm conductivity means the problem is in the sensor or the wiring, not the transmitter.
9100A Sensor Signal Fault Checks
The Foxboro 9100A sensor is robust but not immune to liner damage, electrode coating and grounding problems. Before pulling a sensor, do these tests at the sensor junction box.
First, disconnect all cables. Measure the excitation coil resistance from terminal 1 to terminal 2. For many 9100A sizes from DN25 to DN300 the value should match the factory test sheet, often below 100 Ohm for larger coils. A short to ground or an open coil is a clear sensor failure. If you do not have the factory sheet, measure all three coil pairs if present. The readings should be balanced within 5 percent.
Second, check electrode leakage. Set a megohmmeter to 500 V DC. Measure from each electrode terminal to the sensor body or ground ring. A dry clean sensor should read above 20 megohm. Values below 2 megohm often mean moisture ingress, a cracked liner or a damaged electrode seal. Do not megger across electrodes with the transmitter connected. You may damage the IMT input circuit.
Third, check the ground ring or grounding electrode. On plastic or lined pipe, a missing ground ring causes a noisy signal and a slow zero shift. Customers in Southeast Asia often see this on skid mounted water lines where installers skip the ground ring because the pipe is PVC. The 9100A still needs proper process ground.
Step by Step Fault Isolation
Most engineers skip this part and swap the transmitter first. That is an expensive guess. Use this order instead.
Step 1: Inspect the local display and record the exact error. Empty pipe, coil current fail and span error are not the same.
Step 2: Verify the process is full and conductivity is above 5 µS/cm. Demineralized water under 5 µS/cm can cause signal loss on any mag meter.
Step 3: Check power supply. IMT transmitters run on 85 to 265 V AC or 24 V DC depending on model. A drop below 85 V AC on long cables causes random res

Step 4: Check the signal cable. Separate it from AC motor cables. Keep cable length under 150 m for most installations. A cable run above 100 m with bad shielding may pick up VFD noise from a pump.
Step 5: Run the sensor tests from the junction box. Compare every value with the factory test sheet. If the sensor fails, remove it and inspect the liner and electrodes.
Typical Failures We See on Customer Sites
A chemical plant in Chile had a Foxboro IMT30 reading 0 m3/h on a DN80 acid line. The pipe was full and the transmitter had power. The cause was a damaged PTFE liner near the flange. Acid had reached the metal body and shorted the electrode signal. The sensor needed a re-line or replacement.
A water treatment plant in Vietnam had unstable flow on a DN400 raw water line. The IMT31 showed an empty pipe alarm every few minutes. The actual cause was a loose ground ring on a rubber lined 9100A. Once the ground ring was cleaned and bolted tightly, the signal returned to normal.
These two examples show the same pattern. The transmitter often looks guilty, but the sensor or grounding is the real fault. If you have no spare sensor on site, you can rent or buy a compatible electromagnetic flow meter while the Foxboro unit is repaired.
Silver Instruments Replacement and Repair Support
Silver Automation Instruments is a process instrument supplier based in China. We support water, wastewater, chemical, food and beverage plants in Southeast Asia, Oceania, Latin America, Africa and the Middle East. We do not claim to be a Foxboro authorized service center. But we can help you with a new electromagnetic flow meter when the 9100A sensor or IMT transmitter is beyond repair.
We stock magnetic flow meters from DN15 to DN600 with PTFE, PFA, EPDM and rubber liners. Outputs include 4-20 mA HART, pulse and RS485. Pressure ratings from PN16 to PN40, with temperature up to 120 °C for standard models. For water and wastewater projects, our electromagnetic flow meter price is often 40 to 60 percent lower than replacing a complete Foxboro set.
Send us your pipe size (DN), flow range, pressure in bar, temperature in °C, liner required and the output signal. We will send a technical quote within one business day.
Tel: +86-25-68650347
WhatsApp: +86-25-52155837
WeChat: +86 15365082610
FAQ
What does an empty pipe fault mean on an IMT transmitter?
It means the transmitter detects low impedance or no conductive liquid between the electrodes. Check if the pipe is full, the ground ring is connected, and the process conductivity is above 5 µS/cm.
How do I test a Foxboro 9100A sensor coil?
Disconnect the transmitter. Measure resistance across the excitation coil terminals with a multimeter. Compare the value to the factory test sheet. Open circuit or short to ground means sensor failure.
Can I use a Silver Instruments mag flow meter to replace a Foxboro 9100A?
Yes. We supply flanged mag meters with similar face to face dimensions. Send us your pipe size, liner, pressure, temperature and output requirement for a configured quote.
What conductivity is needed for a mag flow meter?
Most models need at least 5 µS/cm. For low conductivity fluids below 20 µS/cm, tell us the exact µS/cm value so we can check the transmitter sensitivity.
Why does my Foxboro mag meter read zero with no error code?
Check the flow direction, the cutout setting, the coil excitation and the signal cable. A zero reading with no alarm often points to a broken excitation cable or a transmitter analog output set to 4 mA.
