Flow Meter Icon Assets: Free Vector SVG Downloads for UI and Control Software Design
Quick Answer: These flow meter icon assets give engineers a free vector SVG pack for HMI screens, SCADA graphics, P and ID drawings, and panel layout work. The pack covers Coriolis mass flow meters, magnetic flow meters, ultrasonic flow meters, vortex flow meters, oval gear flow meters, thermal mass flow meters, pressure transmitters, and paperless recorders. Download the SVG files directly from this page with no registration.
This free icon set solves a common problem for automation engineers. You need clean symbols for piping and instrumentation diagrams. You also need icons for HMI buttons and SCADA faceplates. Most online vector packs are generic. They do not match real industrial flow meter dimensions or connection types. We built this pack from actual product drawings used by Silver Automation Instruments.
What Is Inside the Flow Meter Icon Pack
The SVG pack includes outline and filled versions of each flow meter type. Every icon is drawn on a 64 by 64 pixel grid. You can scale the vector without losing sharpness. File names follow product categories. For example, the file naming uses coriolis_mass_flow_meter.svg, magnetic_flow_meter.svg, and oval_gear_flow_meter.svg. That helps you search inside a UI asset library.
You also get inline symbols for process connections. Flange, tri-clamp, and threaded ends are shown. Some icons include the signal wire path for 4-20 mA HART output. Others include a local display panel. These details help when you draft a control loop or a PID drawing.
SVG Icon Design Style and File Specs
Each icon uses a 1.5 pixel stroke on a 64 pixel canvas. Default fill color is none for line icons. Filled versions use solid #1f2937 for dark UI backgrounds. You can override the fill with CSS variables or React props. The SVG viewBox is set to 0 0 64 64. There are no external fonts and no embedded raster images. That keeps the file size under 2 KB for most symbols.
Label text inside some icons uses system fonts. That means the icon will pick up the font of your HMI project. If your HMI does not support local fonts, the label remains a vector path. You can edit the text node in any code editor.
Matching Icons to Real Flow Meter Hardware
Here is the thing. An icon should not be a random symbol. It should tell the operator which instrument is on the line. Our free SVG icons match the actual product shape and label style of Silver Instruments devices. The Coriolis mass flow meter icon shows a twin tube sensor with a transmitter housing. The magnetic flow meter icon shows a wafer or flanged body with grounding rings. The ultrasonic flow meter icon shows clamp-on transducers on a pipe.
We have seen this on customer sites many times. A control room operator misreads a generic symbol during a night shift. The wrong pump gets started. An accurate flow meter icon reduces that risk. Use the vortex flow meter icon for steam and gas lines. Use the oval gear flow meter icon for diesel, fuel oil, and viscous fluids above 5 cP. Use the thermal mass flow meter icon for compressed air and biogas lines. The pressure transmitter icon shows a diaphragm seal or gauge style. The paperless recorder icon shows a panel mounted display with graph lines.
For sizing reference, the linked hardware covers pipe diameters from DN15 to DN300. Temperature ratings go from -200 °C to 350 °C depending on the meter type. Pressure ratings reach PN40 or ANSI Class 150 to 600. Output options include pulse, 4-20 mA HART, RS485 Modbus, and optional ATEX Zone 1 certification for hazardous areas.
How to Use the SVG Icons in Control Software Design
You can import the SVG files into WinCC, Ignition, Wo
If you are building a commercial SCADA template, link back to Silver Automation Instruments. That is enough. Do not resell the raw icon pack as a standalone asset. Industrial end users, system integrators, and OEMs in Southeast Asia, Latin America, Africa, the Middle East, and Oceania can use the icons for water and wastewater, oil and gas, chemical, food and beverage, and marine projects.
Why We Offer These Flow Meter Icons for Free
We sell industrial flow meters and process instruments. We know that a good UI design starts with clear instrument symbols. By offering free SVG assets we help engineers build better control systems. Some of those engineers later send us a request for a flow meter quote. That is fine. There is no signup form and no email gate.
In practice, most engineers skip this part and go straight to the download. We kept the process simple. The SVG pack is a single Zip file hosted on this page. You get immediate access.
Which Icon Should You Choose for a Specific Loop
Do not guess on the icon type. Match the icon to the process fluid and the meter technology. For clean water treatment, use the magnetic flow meter icon. For deionized water without conductivity, switch to the ultrasonic flow meter icon. For edible oil batching, choose the oval gear flow meter icon. For high accuracy mass balance in a chemical reactor, choose the Coriolis mass flow meter icon. For saturated steam measurement, choose the vortex flow meter icon. For low flow compressed air leak monitoring, choose the thermal mass flow meter icon.
Last year a customer in Vietnam asked us for a simple way to label flow meters on a water treatment SCADA mockup. He was using a black box symbol for every instrument. The operator could not tell a magnetic flow meter from a pressure transmitter. We sent him this SVG pack. He replaced all black boxes in one afternoon. The mockup passed the plant acceptance test. This is the kind of small fix that avoids confusion later.
A paint manufacturer in Southeast Asia used the oval gear flow meter icon inside a batch control screen. The batch panel now shows the exact meter position for solvent and resin lines. Operators no longer open the wrong valve during recipe changes.
FAQ
Can I use these flow meter icons in a commercial HMI project?
Yes. You can use them in internal and commercial control software projects. Do not resell the raw SVG files as a standalone icon pack.
Which file format is included in the download?
All files are in SVG 1.1 format. Some common line icons also include a PNG preview at 512 by 512 pixels.
Do the icons match Silver Instruments product dimensions?
The icons follow general shape and connection details. For panel layout you should check the actual product data sheet for faceplate cutout and insertion length.
Are there editable source files?
The SVG files are directly editable in any vector editor. You can change stroke width, color, and label text.
Do I need to register to download the icon pack?
No. The download is direct from this page. No email form is required.
Need a real flow meter for the project behind the icon set? Send us your pressure in bar, temperature in degrees Celsius, pipe size in DN, and flow range. Our engineers will reply with a quote and a recommended model. Contact Silver Automation Instruments at Tel +86-25-68650347, WhatsApp +86-25-52155837, or WeChat +86 15365082610.
